Download the LookCam App
Download LookCam from the Apple App Store or Google Play.
No account required. No login needed.
For Compatible OVOLAPTICS Cameras
+More
OVOLAPTICS Camera Wi-Fi Quick Setup Guide
Get your camera online and start recording in just a few minutes.
1
Quick Setup in 7 Steps (Wi-Fi Mode)
Works with
2.4GHz & 5GHz Wi-Fi
2.4GHz & 5GHz Wi-Fi
2
Plug In the Camera
Plug into power, or charge battery-powered models for about 3 hours with a 5V/2A USB power adapter.
Turn on the camera.
3
Connect to Camera Hotspot Wi-Fi
Select and connect to the camera hotspot.
The device ID may start with G, F, or B.
Slow flashing blue light indicates Standby/AP Mode.
“Unsecured Network” is normal for the camera hotspot.
4
Choose Wi-Fi Mode
Open LookCam. A Wi-Fi setup prompt will appear.
Tap “OK” to configure the camera for your home Wi-Fi.
Tap “Cancel” to remain in AP Mode.
5
Connect to Home Wi-Fi
Select your home 2.4GHz or 5GHz Wi-Fi.
Enter the correct Wi-Fi password.
Then tap “OK”.
6
Wait for Connection
40
sec
Quick flash = Connecting • Solid blue = Connected
Wait approximately 40 seconds.
Tap “Keep Wait” if needed. “WiFi Configuration Successful” confirms setup.
7
Change Camera Password
Once the camera is online, change the default password 123456.
2
Recording Settings (After Camera is Online)
Choose 24/7 recording or motion-triggered recording
Auto Record (Continuous Recording)
Best for 24/7 continuous monitoring
Auto Record:
ON
Alarm Record:
OFF
Record Audio:
ON
Loop Record:
ON
Video Duration:
3 mins
Alarm Record (Motion-Triggered Recording)
Best for motion events and push alerts
Auto Record:
OFF
Alarm Record:
ON
Sensitivity:
Medium
Schedule:
As needed
Interval:
30 seconds
Push Notification:
ON
On-Screen Display:
ON
Tips
2.4GHz
5GHz
Dual-Band Wi-Fi
Works with both 2.4GHz and 5GHz networks.
5–8 m
16–26 ft
Keep Router Nearby
Keep the router within 16–26 ft (5–8 m) of the camera during setup.
Check the Wi-Fi Password
An incorrect Wi-Fi password may cause the camera to appear offline.
RESET
5
sec
Reset if Needed
Hold Reset for about 5 seconds when changing Wi-Fi or if the hotspot is missing.
About This OVOLAPTICS Camera Wi-Fi Setup Guide
This quick setup guide is for compatible OVOLAPTICS cameras using the LookCam app and supporting 2.4GHz and 5GHz Wi-Fi. It covers initial camera setup, connecting to the camera hotspot, connecting the camera to a home Wi-Fi network, changing the default camera password, continuous SD card recording, and motion-triggered recording.
During setup, the camera creates its own Wi-Fi hotspot. Seeing “Unsecured Network” when connecting to this hotspot is normal. To connect the camera to your home network, open LookCam and follow the Wi-Fi setup prompt. If you want to remain in direct AP Mode instead, tap “Cancel” at the Wi-Fi setup prompt.
